Off-topic, but maybe somewhat related to MicroPDP-11's... I've got a
MicroVAX I in a BA23 enclosure. I'm presently a bit thrown by the serial
console port. I'm used to the 9pin MicroVAX II ports. From what I've
been told, the DB25-M connector for the console requires a special serial
cable for connecting the MicroVAX I up to a terminal. A null modem cable
is not adequate.
My MicroVax (I and only) handbook vintage 1984 says the cable is a "BC22D-10".
VAX Systems and Options Catalog Oct 1984 describes the BC22D-10 as
"A fully shielded null modem cable". Two DB25F connectors, 6 wires.
The pins in use are 1,2,3,6,7,20. I would expect that "null modem"
means (from one end to the other) connect 2-3, 3-2, 7-7, 6-20, 20-6.
The implication is that the computer might need to see DTR asserted
before it talks to the terminal.
carl
carl lowenstein marine physical lab u.c. san diego
{decvax|ucbvax} !ucsd!mpl!cdl cdl(a)mpl.ucsd.edu
clowenstein(a)ucsd.edu
Received: (from major@localhost)
by minnie.cs.adfa.edu.au (8.9.1/8.9.1) id IAA08853
for pups-liszt; Thu, 4 Feb 1999 08:25:02 +1100 (EST)
From Brian D Chase <bdc(a)world.std.com> Thu Feb 4
07:24:36 1999
Received: from
europe.std.com (
europe.std.com [199.172.62.20])
by minnie.cs.adfa.edu.au (8.9.1/8.9.1) with ESMTP id IAA08845
for <pups(a)minnie.cs.adfa.oz.au>; Thu, 4 Feb 1999 08:24:45 +1100 (EST)
Received: from
world.std.com by
europe.std.com (8.7.6/BZS-8-1.0)
id QAA11267; Wed, 3 Feb 1999 16:24:36 -0500 (EST)
Received: from localhost by
world.std.com (TheWorld/Spike-2.0)
id AA09409; Wed, 3 Feb 1999 13:24:36 -0800
Date: Wed, 3 Feb 1999 13:24:36 -0800 (PDT)
From: Brian D Chase <bdc(a)world.std.com>
To: Carl Lowenstein <cdl(a)mpl.ucsd.edu>
Cc: pups(a)minnie.cs.adfa.oz.au
Subject: Re: MicroVAX I console port question.
In-Reply-To: <199902032037.MAA03843(a)mpl.ucsd.edu>
Message-Id: <Pine.SGI.3.95.990203132057.7730C-100000(a)world.std.com>
Mime-Version: 1.0
Content-Type: TEXT/PLAIN; charset=US-ASCII
Sender: owner-pups(a)minnie.cs.adfa.edu.au
Precedence: bulk
On Wed, 3 Feb 1999, Carl Lowenstein wrote:
My MicroVax (I and only) handbook vintage 1984 says
the cable is a "BC22D-10".
VAX Systems and Options Catalog Oct 1984 describes the BC22D-10 as
"A fully shielded null modem cable". Two DB25F connectors, 6 wires.
The pins in use are 1,2,3,6,7,20. I would expect that "null modem"
means (from one end to the other) connect 2-3, 3-2, 7-7, 6-20, 20-6.
The implication is that the computer might need to see DTR asserted
before it talks to the terminal.
Or given that everything seems to be fine on my end null modem cable-wise,
it's possible that something more serious is wrong with my MicroVAX I.
Does your handbook list what a flashing "1" LED error code means?
I'll double-check my cabling as well.
-brian.
---
Brian "JARAI" Chase |
http://world.std.com/~bdc/ | VAXZilla LIVES!!!
Received: (from major@localhost)
by minnie.cs.adfa.edu.au (8.9.1/8.9.1) id GAA13300
for pups-liszt; Fri, 5 Feb 1999 06:08:49 +1100 (EST)
From Johnny Billquist <bqt(a)Update.UU.SE> Fri Feb
5 05:07:56 1999
Received: from Zeke.Update.UU.SE (IDENT:2026@Zeke.Update.UU.SE
[130.238.11.14])
by minnie.cs.adfa.edu.au (8.9.1/8.9.1) with ESMTP id GAA13295
for <pups(a)minnie.cs.adfa.oz.au>; Fri, 5 Feb 1999 06:08:37 +1100 (EST)
Received: from localhost (bqt@localhost)
by Zeke.Update.UU.SE (8.8.8/8.8.8) with SMTP id UAA06615;
Thu, 4 Feb 1999 20:07:58 +0100
Date: Thu, 4 Feb 1999 20:07:56 +0100 (MET)
From: Johnny Billquist <bqt(a)Update.UU.SE>
To: "Erin W. Corliss" <erin(a)coffee.corliss.net>
cc: pups(a)minnie.cs.adfa.oz.au
Subject: Re: Memory Management
In-Reply-To: <Pine.LNX.3.96.990121163113.412A-100000(a)coffee.corliss.net>
Message-ID: <Pine.VUL.3.93.990204192532.4375B-100000(a)Zeke.Update.UU.SE>
MIME-Version: 1.0
Content-Type: TEXT/PLAIN; charset=US-ASCII
Sender: owner-pups(a)minnie.cs.adfa.edu.au
Precedence: bulk
On Thu, 21 Jan 1999, Erin W. Corliss wrote:
The documentation that Warren gave me describes the
memory management
scheme. It says that when the machine is first started, the memory
management unit is disabled -- anyone know how to enable it, and where the
segmentation registers are (I'm assuming they are in the 0160000-0177777
range somewhere)?
I haven't seen anyone answering this, so here I go...
Reg. Addr.
MMR0 777572
MMR1 777574
MMR2 777576
MMR3 772516
UIPAR 777640-777656
UDPAR 777660-777676
UIPDR 777600-777616
UDPDR 777620-777636
SIPAR 772240-772256
SDPAR 772260-772276
SIPDR 772200-772216
SDPDR 772220-772236
KIPAR 772340-772356
KDPAR 772360-772376
KIPDR 772300-772316
KDPDR 772320-772336
xy in xyP?R is:
x: U - User
S - Supervisor
K - Kernel
y: I - Instruction
D - Data
PAR is Page Address Register
PDR is Page Description Register
Okay, so for the layout of the registers...
MMR0:
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! !
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
! ! ! ! ! ! ! \-/ ! \---/ +-- Enable relocation
! ! ! ! ! ! ! ! ! +------ Page number
! ! ! ! ! ! ! ! +---------- Page address space I/D
! ! ! ! ! ! ! +------------- Page mode
! ! ! ! ! ! +---------------- Instruction completed
! ! ! ! ! +------------------ Maintenance mode
! ! ! ! +-------------------- Enable memory management trap
! ! ! +-------------------------- Trap-Memory management
! ! +---------------------------- Abort-Read only access violation
! +------------------------------ Abort-Page length error
+-------------------------------- Abort-Non resident
The page info is for when a trap/fault occurs, and tells in which page it
occured.The rest should be pretty obvious.
MMR1:
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! !
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
\-------/ \---/ \-------/ \---/
! ! ! +---- Register number
! ! +------------ Amount changed (2 compl.)
! +-------------------- Register numbe
+---------------------------- Amount changed (2 compl.)
Low byte is written first, and this register tells how much registers have
changed part way through an instruction, which needs to be undone to start
the intruction again.
MMR2:
Virtual address of instruction where fault occured.
MMR3:
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! !
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
! ! ! ! +--- Enable user D space
! ! ! +----- Enable supervisor D space
! ! +------- Enable kernel D space
! +----------- Enable 22-bit mapping
+------------- Enable unibus map
If 22-bit mapping isn't enabled, the machine will be in 18-bit addressign
when MMU is enabled. Unibus-mapping is something I'll skip for now. You
need it for DMA on a 22-bit unibus machine only.
Note that at the end of a MMU trap/abort, MMR0 bit 15-12 must be cleared
for MMR1 and MMR2 to become active again.
From a virtual address (VA), you get to the physical
address (PA) like
this:
APF=VA[15:13]
DF=VA[12:0]
PA=PAR(APF)*64+DF
The PDR looks loke this:
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! !
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
\-----------/ ! ! ! \---/
! ! ! ! +----- ACF
! ! ! +--------- ED
! ! +--------------- W
! +----------------- A
+------------------------- PLF
ACF - Access Control Field
000 - Non resident; abort on all accesses
001 - Read only; abort on write attempt, memory mgmt trap on read
010 - Read only; abort on write attempt
011 - Unused; abort on all accesses - reserved for future use
100 - Read/Write; memory mgmt trap upon completion of read or write
101 - Read/Write; memory mgmt trap upon completion of write
110 - Read/Write; no system trap/abort action
111 - Unused; abort on all accesses - reserved for future use
A - Access to page has been made.
W - Page has been written to since PAR/PDR was loaded
ED - Expansion direction
PLF - Page length field
Now, have fun...
Johnny
Johnny Billquist || "I'm on a bus
|| on a psychedelic trip
email: bqt(a)update.uu.se || Reading murder books
pdp is alive! || tryin' to stay hip" - B. Idol
